GTL01 digital controller
The V20 HYPER is equipped with a GTL01 digital controller specifically studied to manage every function of the light tower for the best ease of use.
Top accessibility
3 doors for a wider access. 2 compass-top doors with «wing» shape provide a complete access to the engine for a safe and convenient maintenance. 1 back door allows the access to the digital control panel.
The lowest noise level!
Innovation means also decreasing the noise level! The V20 light tower emits only 58 dB(A) @ 7 meters.
Long running time
Thanks to the V20 HYPER’s fuel saving features such as the small engine and the LED lamps, this model can run up to 143 hours without refueling.
Double power
You can connect a V20 HYPER to another V20 HYPER and run two lighting towers with only one engine.
V20 HYPER Y2 Specifications
Yanmar 2TNV-70
| Minimum dimensions (L x W x H) | 2200 x 1400 x 2440 mm |
| Maximum dimensions (L x W x H) | 2200 x 1850 x 8500 mm |
| Dry weight | 980 kg |
| Lifting system | Hydraulic |
| Mast rotation | 340° |
| Lamps power | 4 x 320 W |
| Lamps type | LED (Hyper) |
| Total lumen | 184000 Lm |
| Illuminated area (180°/360°) | 4500/4200 m2 |
| Engine | Yanmar 2TNV-70 |
| Engine cooling | Liquid |
| Cylinders (q.ty) | 2 |
| Engine speed (50/60 Hz) | 1500 / 1800 rpm |
| Liquid containment (110%) | √ |
| Alternator (kVA/V/Hz) | 5/220/50 – 5/240/60 |
| Outlet socket (kVA/V/Hz) | 2/220/50 – 2/240/60 |
| Inlet plug (A/V/Hz) | 16/220/50 – 16/240/60 |
| Avg. sound pressure | 59 dB(A) @ 7m |
| Wind speed resistance | 110 km/h |
| Tank capacity | 100 l |
| Running time | 143 h |
